Automatic round corner bag powder packing juice powder chocolate powder packing machine

Automatic round corner bag powder packing juice powder chocolate powder packing machine

Hot Sale Price: USD6363$

Machine Model: JS-240C

Automaticity: Full Automatic

Packaging Bag Size:(W)30~600mm (L)50~170mm

Film Width: Max.240mm

Packing Speed:30~60bag/min

Material: SUS304

Machine Size: (L)900*(W)700*(H)1700mm

Machine Weight: 400KG


Share:
  • Product Introduction
  • Product Parameters
  • Contact Us
Feature

1. The machine is suitable for food products of particles, powder, liquid, paste and another measurement packing.

2. All the works of bag making, measuring, filling, sealing, cutting and counting can be done automatically, at the same time, it can also according to the demand of customers to add printer and other options.

3. The touch screen operation, PLC control, drives stepper motor to control the bag length, stable performance, easy to adjust and accurate detection.

4. Packing material: BOPP/Polyethylene, Aluminum/Polyethylene, Paper/Polyethylene, Polyester/Plated Aluminum/Polyethylene, Nylon/CPP and so on.


Application

All Kind Of Powder product: milk powder, coffee powder, tea powder, soybean powder, flour, protein powder, spice powder, etc.

Full automatic small sachet coffee powder juice powder packing machine

Automatic hot chocolate powder stick packing machine


Samples

Full automatic round bag packing matcha tea powder packing machine

Specification

Full automatic round bag packing matcha tea powder packing machine

  1. Connect to power, set the packaging parameter on the touch screen, waiting for the sealing temperature to setting value.

  2. Pull the packaging film to the packing machine, and pull the film to bag former, put the material to hopper.

Full automatic round bag packing matcha tea powder packing machine

3.When the sealing temperature to setting value that can turn on the machine, the packaging machine will auto pulling to bag former, auto bag making.

4. Measuring screw will auto measuring material and auto bagging.

Full automatic round bag packing matcha tea powder packing machine

5. After bag making, the product will stereotype by vertical sealing device.

6. Finished product will cut out by the cutting device, you will get a beautiful product.


Combined Parts
None
Request a quote
ModelJS-240C
Bag length50~170mm
Bag width30~60mm
Film width240mm
Measuring range10-50ml
Packing speed30~60bag/min
power220V,1.9kW,50/60HZ
Machine size900*700*1700mm
Sealing type3/4 side seal, back seal
Machine weight400kg
