Best Quality JS-420AZ High Speed Doy Pack Machine
JASON best quality JS-420AZ high speed doy pack machine has material feeding, weighing, pouch packing functions, it is suitable for packing snacks, dried fruit, nuts, frozen food, etc.
1. The operation is controlled by PLC and large-screen touch screen. The operation is simple and convenient.
2. Supporting fault automatic tracking alarm system, real-time display of operating status.
3. The mechanical empty bag tracking and detection device can realize the bag opening, blanking and sealing.
4. The main drive system adopts frequency conversion stepless speed regulation control, full cam transmission, stable operation and low failure rate.
5. The design of the whole machine complies with GMP standards and has passed CE certification.
Application
| Packing speed | 10-80bags/min |
| Packing specification | L≤350mm, W:80-210mm |
| Packing form | Pre-made bag |
| Air source | 6kg/c㎡, 500L/min |
| Packaging material | PE composite film |
| Machine weight | 1670kg |
| Power supply type | 380V, 50HZ |
| Total power | 8kw |
| Dimensions | 5900*2070*3350mm |
| Packing weight | 10-1500g |
